V8 loudspeaker and V subwoofer

◉SPLmax 142 dB

V8 dual 10-inch three-way line array speaker (4+1) combination

1. It is used in combination with 4 V8 high performance 3-way passive line array loudspeaker and 1 V-SUB high performance flyable cardioid subwoofer.

2. The V8 is a 3-way passive design with built-in 2 x 10" low frequency drivers, 1 8" MF driver with horn and 2 1.4" exit high frequency compression drivers, 2.5" voice coil mounted on a dedicated waveform shaping on the device.

3. It can be used in columns of pure V8 speakers or combined with V-SUB. The symmetrical bipolar arrangement of the neodymium LF drivers around the center-mounted coaxial MF and HF components allows the intersecting frequency bands to overlap smoothly in a crossover design.

4. The V8 cabinet is made of marine plywood with an impact and weather resistant PCP (Polyurea Cabinet Protection) surface.

5. V-SUB is a high performance flyable cardioid subwoofer.

◉Components 18"/12"
◉Dispersion Cardioid
◉SPLmax 137 dB

The V-SUB is an actively driven high performance cardioid subwoofer powered by a single amplifier channel.

It contains two long-excursion neodymium drivers, a front-facing 18-inch driver in a bass-reflex design, and a rear-radiating two-chamber bandpass design 12-inch driver.
