Dual channel condenser digital wireless microphone AXT200s
- Model
- AXT200s
Item specifics
- UHF frequency range
- 615-665mhz, 780-820mhz.
- Working effective distance
- 100 meters long range
- Microphone capsule
- Condenser capsule
- Application
- Stage Performance
- Type
- professional digital wireless microphone
- Feature
- High sensitivity ，Perfect Sound,
- Channels
- dual channel
- Maximum deviation
- ± 45kHz
- Integrated S / N ratio
- > 108 dB
- Color
- Black
Review
Description
✔ Ultra High Frequency
✔ True diversity circuit
True diversity A, B dual-channel frequency wave
A, B channel 0 seconds cutover
Ensure the signal is stable and reliable
✔ Configuring ID code lock
✔ Point to point encrypt
With a separate ID code assignment, the receiver locks the corresponding transmitter ID code, greatly reducing crosstalk.
✔ DPLL channel synthesis
✔ There are 800 available frequency point
The stable DPLL phase-locked oscillating circuit, combined with noise detection and mute control function, can reduce noise and radio frequency interference such as computer equipment, karaoke machines and DVDs in the environment.
Modulation method: FM
Oscillation method: PLL phase-locked frequency synthesizer
Frequency stability: ± 0.0005%
Sensitivity: S / N> 60dB when the offset is equal to 25KHz and input 6dBμV
Maximum deviation: ± 45kHz
Bandwidth: 40MHz
Integrated S / N ratio:> 108 dB
General T.H.D.: <0.4% @ 1 KHz
Integrated frequency response: 65Hz ~ 18kHz ± 3dB
Maximum output voltage: Balanced: -20dBV / 100Ω
Unbalanced: -4dBV / 5KΩ
Output socket: XLR balanced and 6.3φ unbalanced socket
Power supply: 100 - 240V AC50 / 60 Hz, 10W
Frequency range: UHF 615-665mhz, 780-820mhz
Oscillator mode: PLL phase-locked frequency synthesizer
Harmonic radiation: <-63dBm
Bandwidth: 80MHz
Maximum deviation: ± 45KHz
Power output: 30mW
Frequency response: 50Hz ~ 18KHz
The maximum input sound pressure: 130dB SPL
Soundhead: Condenser capsule
Battery: AA × 2
Current consumption: <110 mA
