Powered Column Speaker Syva 2 way passive for Home theater conference hall
- Model
- Syva
Item specifics
- Type
- 2 way passive column speaker
- Max SPL
- 137 dB
- Bandwidth
- 87 Hz- 20 KHz
- Transducers
- LF : 6 x 5" ; HF : 3 x 1.75"
- Weight
- 21 kg
- Application
- Home theaters, conference halls, shopping malls
Review
Description
Syva Description
| 2-way passive 5 inch Syva Specification | |
| Transducers | MF: 6 x 5" cone drivers HF: 3 x 1.75" diaphragm compression drivers |
| Coverage (-6 dB) | Vertical directivity: +5 /-21° Horizontal directivity: 140° |
| Nominal impedance | 8Ω |
| Usable bandwidth (-10dB) | 87Hz-20kHz (-10dB) |
| RMS power handling | 454W |
| Maximum SPL | 137dB |
| Acoustical load | LF: bass-reflex HF: waveguide |
| Cabinet | First grade plywood |
| Front | Coated steel grill Acoustically neutral 3D fabric |
| Connectors | 1 x 4-point speakON 1 x 2-point screw terminal 1 x AutoConnect |
| Dimensions (W x H x D) | 144 mm x 1304 mm x 209 mm |
| Weight (net) | 21 kg / 46 lb |
Feature of Syva
●Streamlined design.
●Exceptional coverage capability.
●Clear vocals and smooth horizontal polar pattern.
●Clear low-frequency power.
●Syva can be stacked on top of Syva Low. (Four magnets and grooves on the bottom of the case ensure stability).
●There are two threaded inserts on the back of the Syva for attaching special rigging accessories.
●Exceptional coverage capability.
●Clear vocals and smooth horizontal polar pattern.
●Clear low-frequency power.
●Syva can be stacked on top of Syva Low. (Four magnets and grooves on the bottom of the case ensure stability).
●There are two threaded inserts on the back of the Syva for attaching special rigging accessories.
Top of Syva
Middle of Syva
Bottom of Syva
can be connected with Syva Low
Back of Syva
can be connected with
special rigging accessories
Syva Low Description
| Syva Low Specification | |
| Low frequency limit (-10 dB) | 40 Hz |
| Directivity | Standard |
| Maximum SPL | 137 dB |
| Transducers | 2 × 12″ cone drivers |
| Acoustical load | Load bass-reflex |
| Nominal impedance | 4 Ω |
| Connectors | 1 × 4-point speakON |
| 1 x AutoConnect | |
| Weight (net) | 29 kg / 64 lb |
| Cabinet | First Grade plywood |
| Front | Coated steel grill |
| acoustically neutral 3D fabric | |
Feature of Syva Low
●High-power handling and high-excursion driver for maximized output and bandwidth.
●Beautifully extends a Syva source with autoconnect.
●Clear low-frequency power.
●Can be incorporated into any venue decor.
●Beautifully extends a Syva source with autoconnect.
●Clear low-frequency power.
●Can be incorporated into any venue decor.
