Sinbosen FP10000Q 4 channel professional power amplifier for dual 15 inch speaker

Min. Order 1 piece
Terms of Payment Western Union, MoneyGram, T/T, Paypal
Update Time 2019-12-27
Item specifics
Channels4 channel power amplifier
TypeTouring Amplifier
8Ω Output Power1350W x 4
4Ω Output Power2100W X 4
ColorBlack, Blue
CertificationCE ROHS, TUV
Warranty3 Years
CapacitorsSiemens capacitors 3300uf/200V
Special serviceOEM service offered

Sinbosen FP10000Q: One FP10000q amplifier can use with 4 pcs Dual 15-inch speaker

FP10000Q some materials information as follow:

1. Extended 34mm heatsink, longer and thicker.

2. High-quality Blue amplifier board.

3. Use original "Sanken" and "Fairchild" transistor.

4. Use high-quality fans from Taiwan.

5. Use original "Siemens" capacitors.

- 10pcs 3300uf/200V

- 4pcs 1800uf/200V

6. Use Switzerland XLR Brand -- Neutrik


8 ohms Stereo Power: 4x1350W

4 ohms Stereo Power: 4x2100W

8ohms Bridged Power: 2x4200W

4ohms Bridged Power: 2x5000W

Frequency Response(+0/-0.3dB,1W/8Ω): 20 Hz - 34 kHz

THD 20 Hz - 20 kHz for 1 W: <0.1%

Signal-to-Noise Ratio: >112 dBA

Channel separation (Crosstalk) at 1 kHz: >70 dB

Input Connectors (per channel): 3-pin XLR, electronically balanced

Output Connectors (per channel): Binding Posts 2-pole

TourClass Protection: ACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush,sub/ultrasonic input

Operating voltage, 230 V / 115 V nominal: 130-265 V / 65-135V selectable

Voltage Gain(dB): 23, 26, 29, 32, 35, 38, 41, 44 dB selectable

Input impedance: 20 kOhm

Level adjustment (per ch.): Front-panel potentiometer, 31 position detented from -inf to 0 dB

Dimensions (W*H*L): 88mmX483mm×396mm

Packing dimension (W*H*L): 180mmX560mm×500mm

Net weight: 12.5kg

Gross weight: 14.5kg

Sinbosen FP10000Q Feedbacks:

Hold 6000 People Party in the NetherlandsThe Rock Festival In San Luis Potosí, MexicoFestival brassicole trois rivières in Canada

Must know before buying:

Full-range speaker [line array speaker, professional speaker]: the power of the power amplifier should be greater than 1.5 times or more;

Subwoofer speaker: The power of the amplifier should be more than 2 times or more, because the current of the low frequency speaker is larger than that of the full frequency speaker!
