Model
FP 14000

Item specifics

Channels
2 channel power amplifier
Type
Professional Power Amplifier
8Ω Output Power
2400WX2CH
4Ω Output Power
4400WX2CH
Color
Black, Blue
Certification
CE, ROHS, TUV
Class
TD
Warranty
3 Years
Capacitors
3300uf/200V
Special service
OEM service offered
For
Dual 18 inch subwoofer
Application
Karaoke/KTV/Cinema/Church/Stage/Concert/DJ

Review

Description

Sinbosen high power 4400w 2 channel lab FP14000 amplifier for dual 18-inch bass

One FP 14000 switch high power amplifier can use with 2 pcs Dual 18 inch speaker









FP14000 SPECIFICATIONS


8 ohms Stereo Power: 2x2400W

4 ohms Stereo Power: 2x4400W

8 ohms Bridged Power: 8800W

4 ohms Bridged Power: 14000W

Frequency Response(+0/-0.3dB,1W/8Ω): 20 Hz - 34 kHz

THD 20 Hz - 20 kHz for 1 W: <0.1%

Signal-to-Noise Ratio: >112 dBA

Channel separation (Crosstalk) at 1 kHz: >70 dB

Input Connectors (per channel): 3-pin XLR, electronically balanced

Output Connectors (per channel): Binding Posts 2-pole

TourClass Protection: ACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush,sub/ultrasonic input

Operating voltage, 230 V / 115 V nominal: 130-265 V / 65-135V selectable

Voltage Gain(dB): 23, 26, 29, 32, 35, 38, 41, 44 dB selectable

Input impedance: 20 kOhm

Level adjustment (per ch.): Front-panel potentiometer, 31 position detented from -inf to 0 dB




Newly upgraded version FP14000 amplifier details


1. Longer heatsink +30mm, so now 94mm!

2. Use original "Siemens" capacitors.

- 12pcs 3300uf/200V (+2 pcs more than the old version)

- 4pcs 2200uf/200V

3. High-quality Blue amplifier board.

4. Use original "Sanken" and "Fairchild" transistor.

5. Use high-quality fans from Taiwan.

6. Use Switzerland XLR Brand -- Neutrik.




FP 14000 Power Amplifier Feedback and Video



Use FP14000 For 6000 People Party in the NetherlandsUse FP14000 At The Rock Festival In San Luis Potosí, MexicoFP14000 Used For Canada Brassicole Trois Rivieres Festival




Must know before buying:

Full-range speaker [line array speaker, professional speaker]: the power of the power amplifier should be greater than 1.5 times or more;

Subwoofer speaker: The power of the amplifier should be more than 2 times or more, because the current of the low frequency speaker is larger than that of the full frequency speaker!
