SKM 9100

Item specifics

working range
100 Meter
Frequency range
615-655 MHz , 780-822 MHz
Power supply
2×1.5V AA battery
Audio Frequency Response
Oscillation mode
PLL frequency synthesizer (PLL)
Series model



Technical parameters
Frequency Range: 615-655MHz
Oscillation mode: PLL frequency synthesizer (PLL)
Frequency stability: ± 10ppm
Receiving Mode: superheterodyne double conversion
Receiver sensitivity: -90dBm
Audio Frequency Response: 40-18000Hz
Harmonic Distortion: ≤ 0.5%
Signal to Noise Ratio: ≥ 100dB
Audio output (independent and mixed unbalanced output): 10-30mW transmit power
Modulation: Frequency Modulation (FM)
Battery Specifications: two on the 5th battery
Power Specifications: 100-240V 50-60Hz (switch power adapter)

Support manual FM mode and automatic sweep mode
Modulation signal sensitivity based on different occasions
Small size easy to carry
Can connect with the headset mic or clip mic
Colors are available for various occasions
The optional rose gold, champagne gold, matte black three

UHF 800MHz band, phase-locked loop (PLL) frequency synthesizer
One for two, 150X2 channel adjustable
Infrared frequency, automatic synchronization lock the transmitter frequency
The receiver automatically scans and locks the current environment is best to use free channels.
Hair shooter microphone with two tranches of power regulation, meet the requirements of multi-use
Superheterodyne double conversion design, with a high receiver sensitivity
Multi-level high-performance surface acoustic wave filters, with the excellent anti-jamming capability
Mute circuit specially designed to completely eliminate the microphone
turned on and off the impact of noise"
Microphone use Tesco on the 5th battery continued up to 6-8 hours
Microphone dual step-up design, the battery down does not affect the transmit power
The ideal environment for operating radius of 100 meters, used in a variety of high demand occasions
The default configuration for the microphone T9
